| Brand | ASRock |
|---|---|
| Reference | 250402-1A2D |
| ProductSpecs.colors | Black |
| Copper | |
| Height | 330 mm |
| Materials | Aluminum |
| Copper | |
| Glass | |
| PCB | |
| ProductSpecs.eccSupport | Yes |
| ProductSpecs.biosFeatures | dualBios: false, clearCmos: true, flashback: true |
| Chipset | AMD B550 |
|---|---|
| CPU Socket | AMD AM4 |
| Supported CPUs | 1 |
| Maximum Memory | 128 Go |
|---|---|
| Memory Type | DDR4 |
| Memory Slots | 4 |
| Memory Channel | Dual Channel |
| Max Memory per Slot | 32 Go |
| Supported Memory Frequencies | 2133 MHz |
| 2400 MHz | |
| 2667 MHz | |
| 2933 MHz | |
| 3200 MHz | |
| 3466 MHz | |
| 3600 MHz | |
| 3733 MHz | |
| 3800 MHz | |
| 3866 MHz | |
| 4000 MHz | |
| 4133 MHz | |
| 4200 MHz | |
| 4266 MHz | |
| 4333 MHz | |
| 4400 MHz | |
| 4466 MHz | |
| 4533 MHz | |
| 4600 MHz | |
| 4666 MHz | |
| 4733 MHz | |
| 4933 MHz |
| Integrated Graphics | Yes |
|---|---|
| CPU Integrated Graphics Compatible | Yes |
| PCI Slots | PCIe 4.0 x16 |
|---|---|
| 2x PCIe 3.0 x16 (x4) | |
| PCIe 3.0 x1 | |
| Multi-GPU Type | CrossFireX |
| Audio Chipset | Realtek ALC897 7.1 channels |
|---|---|
| Audio Channels | 7 |
| Wi-Fi | No |
|---|---|
| Bluetooth | No |
| Ethernet Controllers | 2.5 Mbps Killer E3100G |
| RAID Supported | Yes |
|---|---|
| Storage Connectors | 6x SATA 3.0 |
| 1x M2 | |
| 1x M2 | |
| 1x M2 | |
| Supported RAID Modes | 0 |
| 1 | |
| 10 |
| Rear I/O | 1x HDMI 2.1 |
|---|---|
| 1x OPTICAL_AUDIO | |
| 1x USB-A 3.2 Gen2 | |
| 1x USB-C 3.2 Gen2 | |
| 6x USB-A 3.2 Gen1 | |
| 2x USB-A 2.0 | |
| 1x PS2 | |
| 1x RJ45 2.5G | |
| 1x SMA | |
| 6x AUDIO_JACK |
| Internal Connectors | 1x POWER_ATX 24-pin |
|---|---|
| 2x POWER_CPU 8-pin | |
| 1x FAN | |
| 1x FAN | |
| 5x FAN | |
| 2x LED_RGB | |
| 2x LED_ARGB | |
| 3x USB_2_0 9-pin | |
| 2x USB_3_0 | |
| 1x USB_3_2 | |
| 1x PANEL_FRONT | |
| 1x AUDIO_FRONT 10-pin | |
| 1x TPM 20-pin | |
| 1x THUNDERBOLT 5-pin |
| Usage | Gaming |
|---|---|
| LED Lighting | Yes |
| Connector Placement | Standard |
| Overclocking Features | Yes |
| Width | 243.84 mm |
|---|---|
| Length | 304.8 mm |
| Form Factor | ATX |
