| Brand | ASUS |
|---|---|
| Reference | 90MB1MPP-M0EAYC |
| ProductSpecs.colors | Green |
| Height | 50 mm |
| Materials | Aluminum |
| PCB | |
| ProductSpecs.biosFeatures | dualBios: true, clearCmos: true, flashback: true |
| Chipset | Intel Q870 |
|---|---|
| CPU Socket | Intel 1851 |
| Supported CPUs | 1 |
| Maximum Memory | 128 Go |
|---|---|
| Memory Type | DDR5 |
| Memory Slots | 2 |
| Memory Channel | Dual Channel |
| Max Memory per Slot | 64 Go |
| Supported Memory Frequencies | 4800 MHz |
| 5200 MHz | |
| 5400 MHz | |
| 5600 MHz | |
| 6400 MHz |
| Integrated Graphics | No |
|---|---|
| CPU Integrated Graphics Compatible | Yes |
| PCI Slots | PCIe 5.0 x16 |
|---|
| Audio Chipset | Realtek 7.1 Surround Sound High Definition Audio CODEC |
|---|---|
| Audio Channels | 7 |
| Ethernet Controllers | 1 Mbps Intel I219LM |
|---|
| RAID Supported | Yes |
|---|---|
| Storage Connectors | 1x M2 |
| 2x SATA 3.0 | |
| Supported RAID Modes | 0 |
| 1 | |
| 5 | |
| 10 |
| Rear I/O | 3x USB-A 3.2 |
|---|---|
| 1x USB-C 3.2 | |
| 2x USB-A 2.0 | |
| 3x AUDIO_JACK | |
| 1x RJ45 1.0 | |
| 2x DISPLAYPORT 1.4 | |
| 1x HDMI 2.1 | |
| 2x PS2 |
| Internal Connectors | 1x POWER_ATX 24-pin |
|---|---|
| 1x POWER_CPU 8-pin | |
| 2x FAN 4-pin | |
| 1x USB_3_2 19-pin | |
| 1x USB_3_1 19-pin | |
| 1x USB_2_0 19-pin | |
| 1x AUDIO_FRONT 9-pin | |
| 1x PANEL_FRONT 10-pin | |
| 1x CHASSIS_INTRUSION | |
| 2x COM | |
| 1x OTHER | |
| 1x OTHER |
| Usage | Server |
|---|---|
| Workstation | |
| LED Lighting | No |
| Connector Placement | Standard |
| Overclocking Features | No |
| Width | 170 mm |
|---|---|
| Length | 170 mm |
| Form Factor | Mini-ITX |
