| Brand | Biostar |
|---|---|
| Reference | 251106-6E0F |
| ProductSpecs.colors | Black |
| Gold | |
| Red | |
| Height | 0 mm |
| Materials | Aluminum |
| Copper | |
| PCB | |
| ProductSpecs.biosFeatures | dualBios: true, clearCmos: true, flashback: true |
| Chipset | Intel Z590 |
|---|---|
| CPU Socket | Intel 1200 |
| Supported CPUs | 1 |
| Maximum Memory | 128 Go |
|---|---|
| Memory Type | DDR4 |
| Memory Slots | 4 |
| Memory Channel | Dual Channel |
| Max Memory per Slot | 32 Go |
| Supported Memory Frequencies | 2133 MHz |
| 2400 MHz | |
| 2666 MHz | |
| 2800 MHz | |
| 2933 MHz | |
| 3200 MHz | |
| 3600 MHz | |
| 3733 MHz | |
| 3800 MHz | |
| 3866 MHz | |
| 4000 MHz | |
| 4133 MHz | |
| 4266 MHz | |
| 4333 MHz | |
| 5000 MHz |
| Integrated Graphics | No |
|---|---|
| CPU Integrated Graphics Compatible | Yes |
| PCI Slots | PCIe 4.0 x16 |
|---|---|
| PCIe 4.0 x16 (x8) | |
| PCIe 3.0 x16 (x4) |
| Audio Chipset | Realtek ALC1220 7.1 channels |
|---|---|
| Audio Channels | 7 |
| Wi-Fi | No |
|---|---|
| Bluetooth | No |
| Ethernet Controllers | 2.5 Mbps Realtek RTL8125B |
| RAID Supported | Yes |
|---|---|
| Storage Connectors | 6x SATA 3.0 |
| 1x M2 | |
| 1x M2 | |
| 1x M2 | |
| Supported RAID Modes | 0 |
| 1 | |
| 5 | |
| 10 |
| Rear I/O | 1x PS2 |
|---|---|
| 1x HDMI 2.0 | |
| 1x DISPLAYPORT 1.4 | |
| 1x USB-C 3.2 | |
| 5x USB-A 3.2 | |
| 2x USB-A 3.2 | |
| 1x RJ45 2.5G | |
| 2x SMA | |
| 5x AUDIO_JACK | |
| 1x S_PDIF |
| Internal Connectors | 1x POWER_ATX 24-pin |
|---|---|
| 2x POWER_CPU 8-pin | |
| 1x FAN 4-pin | |
| 1x FAN 4-pin | |
| 3x FAN 4-pin | |
| 2x FAN 4-pin | |
| 2x USB_2_0 19-pin | |
| 1x USB_3_1 19-pin | |
| 1x OTHER | |
| 1x PANEL_FRONT 20-pin | |
| 1x AUDIO_FRONT 9-pin | |
| 1x OTHER | |
| 1x LED_RGB 4-pin | |
| 2x LED_ARGB 3-pin | |
| 1x OTHER | |
| 1x OTHER | |
| 1x COM 9-pin | |
| 1x TPM | |
| 1x THUNDERBOLT | |
| 1x BIOS_BUTTON | |
| 1x OTHER | |
| 1x OTHER |
| Usage | Gaming |
|---|---|
| Workstation | |
| LED Lighting | Yes |
| Connector Placement | Standard |
| Overclocking Features | Yes |
| Width | 244 mm |
|---|---|
| Length | 304 mm |
| Form Factor | ATX |
